AK ERM 2480 Scanning head for incremental angle encoder with magnetoresistive scanning Line count: 2048 Grating period: 395.0 µm Drum outside diameter: 257.50 mm Output signal: ~1Vpp Cutoff frequency (-3 dB):300.00 kHz Reference mark: analog Power supply: 5 V (+-10 %) Degree of protection: IP67 (EN60529) Operating temperature: -10/+100 °C Electrical connection: Coupling M23, male, 12-pin Pin configuration: D294999 Connecting direction: Cable outlet tangential (right) Cable length: 1.00 m Cable type: PUR Ø 4.5 mm
