AK ERM 2480 Scanning head for incremental angle encoder with magnetoresistive scanning Line count: 1024 Grating period: 395.0 µm Drum outside diameter: 128.75 mm Output signal: ~1Vpp Cutoff frequency (-3 dB):300.00 kHz Reference mark: analog Power supply: 5 V (+-10 %) Degree of protection: IP67 (EN60529) Operating temperature: -10/+100 °C Electrical connection: Coupling M23, male, 12-pin Pin configuration: D294999 Connecting direction: Cable outlet tangential (right) Cable length: 1.00 m Cable type: PUR Ø 4.5 mm HEIDENHAIN 读数头 1144048-02 AK ERM 2480 1024 HEIDENHAIN 读数头 1144048-03 AK ERM 2480 1200 HEIDENHAIN 读数头 VSP 1144048-55 AK ERM 2480 1024 HEIDENHAIN 读数头 1144048-61 AK ERM 2480 1400 HEIDENHAIN 读数头 315420-03 AE LB 382 HEIDENHAIN 编码器 VSE 1169566-05 ERN 1331 1024 62S12-30 HEIDENHAIN 编码器 1169566-52 ERN 1331 1024 62S12-30 HEIDENHAIN 编码器 VSE 1169566-56 ERN 1331 2048 62S12-30 HEIDENHAIN 电缆 310128-01 APK 02 05 1,00 HEIDENHAIN 电缆 310199-06 APK 03 08 6,00 HEIDENHAIN 长度计 331314-02 MT 1281 HEIDENHAIN 长度计 331667-01 MT 2571 TTLx5 HEIDENHAIN 过滤器 SD4 348249-01 DA 300 HEIDENHAIN 编码器 376886-0B ROD 486 5000 27S12-03 HEIDENHAIN 长度计 376990-01 MT 1287
