375137-01 ST 3077长度计现货，海德汉现货

ST 3077
Incremental length gauge HEIDENHAIN-SPECTO
Plunger actuation:      Extended with compressed
                        air
Measuring length:       30 mm
Type of guide:          ball guide
Reference mark position:5 mm
Accuracy grade:         1.0 µm
Electrical connection:  D-sub connector, 2-row,
                        with locking screws, with
                        integrated electronics,
                        coated, male, 15-pin
Connecting direction:   axial
Pin configuration:      D510107
Cable type:             PUR Ø 5.1 mm
Cable length:           1.50 m
Output signal:          Square-wave signals, TTL
                        levels with 5-fold
                        interpolation
Max. scanning frequency:100.00 kHz
Reference pulse width:  90°
Fault detection signal: for disturbance LOW
Signal period:          4.000 µm
Power supply:           5V+-10%
Degree of protection:   IP64 (EN60529)
Operating temperature:  +10/+40 °C

LC 193F/50nm ML 1340mm ID 557676-13

LC 193F/50nm ML 1440mm ID 557676-14

LC 193F/50nm ML 1540mm ID 557676-15

LC 193F/50nm ML 1640mm ID 557676-16

LC 193F/50nm ML 1740mm ID 557676-17

LC 193F/50nm ML 1840mm ID 557676-18

LC 193F/50nm ML 2040mm ID 557676-19

LC 193F/50nm ML 2240mm ID 557676-20

LC 193F/50nm ML 2440mm ID 557676-21

LC 193F/50nm ML 2640mm ID 557676-22

LC 193F/50nm ML 2840mm ID 557676-23

LC 193F/50nm ML 3040mm ID 557676-24
