| HEIDENHAIN | 长度计 | 383963-02 ST 1278 TTLx5 90°出线 IP64 |
| HEIDENHAIN | 编码器 | 534904-18 ROD 1080 1000 |
| HEIDENHAIN | 编码器 | 586657-03 EQN 425 512 |
| HEIDENHAIN | 读数头 | 325693-0K AK ERA 780C 64000 |
| HEIDENHAIN | 编码器 | 1132407-01 EQN 425 512 |
| HEIDENHAIN | 读数头 | 1144048-29 AK ERM 2480 2600 |
| HEIDENHAIN | 编码器 | 376834-20 ROD 430 1024 |
| HEIDENHAIN | 光栅尺 | 526971-12 LS 187 1240 5,0 |
| HEIDENHAIN | 编码器 | 385480-48 ERN 480 1024 |
| HEIDENHAIN | 编码器 | 376886-31 ROD 486 2048 |
| HEIDENHAIN | 电缆 | 643450-03 APK 02 05 3,00 |
| HEIDENHAIN | 角度编码器 | 383601-12 ROD 880C 36000 5m M23 male 12-pin |
| HEIDENHAIN | 编码器 | 534904-05 ROD 1080 1000 |
| HEIDENHAIN | 夹紧套 | 386811-01 Clamping sleeve |
| HEIDENHAIN | 光栅尺 | 689680-17 LC 485 920 5,0 |
| HEIDENHAIN | 模块 | 671968-01 UM 111BD |
| HEIDENHAIN | 光栅尺 | 760942-09 LC 495S 470 5,0 |
| HEIDENHAIN | 电缆 | 360645-06 APK 02 05 6,00 |
| HEIDENHAIN | 光栅尺 | 526974-06 LS 187C 640 5,0 |
| HEIDENHAIN | 光栅尺 | 315418-13 LB 382C 2840 5,0 |
| HEIDENHAIN | 电缆 | 360645-03 APK 02 05 3,00 |
Identnumber
231011-03
Plunger actuation
Extended by spring force
Measuring length
12 mm
Type of guide
sliding glide
Reference mark position
5.5 mm
Accuracy grade
1.0 µm
Electrical connection
Connector M23, male, 9-pin
Pin configuration
D295051
Cable type
PUR Ø 4.5 mm
Cable length
1.50 m
Output signal
sinusoidal current signals (11 µApp)
Signal period
10.000 µm
Power supply
5V+-5%
Degree of protection
IP64 (EN60529)
Operating temperature
+10/+40 °C
SCIP ID
c397871b-5499-46a2-9159-bfef4a2dc632
