LC 415 1140 3,0 EnDat22 ..689673-20
简要介绍：
LC 415 1140 3,0 EnDat22 .. 1,000 14A 0MS14-LY .. .. 01 .. AE 1 689673-20
产品详情
689673-20
LC 415 Absolute sealed linear encoder with small cross section Measuring length: 1140 mm Total length: ML+105 mm Accuracy grade: ± 3.0 µm Grating period: 20.000 µm Measuring step 1: 1.0000 nm Fastening type: End block + mounting spar End block: 14A Output signal: no specified value Output code: Binary Data interface: EnDat22 Synchronous serial EnDat 2.2 without incremental signals Power supply: 3.6 V ... 14 V Electrical connection: Flange socket, male, 14-pin Special characteristics, linear encoder: none
