RON 285C 18000 03S12-03 Heidenhain ID 358699-01
简要介绍：
RON 285C 18000 03S12-03 Heidenhain ID 358699-01
产品详情
RON 285C Incremental angle encoder with integral bearing and integrated stator coupling Line count: 18000 System accuracy: ±5.0'' Output signal: ~1Vpp Cutoff frequency (-3 dB): 180.00 kHz Reference mark: analog, ref. mark coded, nominal increment 1000 Power supply: 5 V (+-10 %) Flange version: Rectangular flange with 85 mm centering collar, drainage channels, aluminum Shaft: Hollow through shaft for axial clamping, diameter 20 mm Protection rating for housing: IP64 (EN60529) Operating temperature: -10/+70 °C Electrical connection: Coupling M23, male, 12-pin Pin configuration: D294999 Connecting direction: Cable outlet for axial and radial use Cable length: 1.00 m Special characteristics, rotational encoders: none
